【Voltage Compatibility】
When using electrical appliances, please note that they are designed for Japanese voltage specifications (90-110V), so if you use them with a different voltage, it may cause a malfunction.
【Plug Type】
Our products use Japanese plug types (A or B type).
Please use a conversion adapter if necessary.
【Important Note on Transformers and Adapters】
A transformer adjusts voltage to match your device’s requirements.
A conversion adapter only changes the plug shape and does not adjust voltage.
Using only a conversion adapter without a transformer may result in damage to the product.
【Liability】
We are not responsible for malfunctions or damages caused by improper use, such as operating the product without a transformer.
----------------------------------------------------------------------
For woodworking such as wood and plywood. Any other use is dangerous and increases the possibility of accidents. Please check the product guide and documentation instructions at the bottom of the page before purchasing.
Voltage: AC100V, Frequency: 50/60Hz, Current: 7.5A, Rated power consumption: 705W
No-load rotation speed: approx. 5,000min-1
Saw blade inclination angle: 0 (vertical) ~ 45 degrees
Usable saw blade: outer diameter 140~147mm, inner diameter 20mm, for woodworking
Attached saw blade dimensions: outer diameter 147mm, inner diameter 20mm, blade thickness 1.6mm, number of teeth 40P
Cord length: approx. 5m, rated time: 30 minutes
Body size: approx. length 259 x width 202 x height 210 (mm), weight: approx. 2.7kg
Set contents: Parallel ruler x 1, hex wrench x 1, woodworking tip saw (set in the main unit) x 1
